OVERCURRENT CIRCUIT BREAKER 6KA 1P B 63A S-A00-S7-1P-B63

Name: OVERCURRENT CIRCUIT BREAKER 6KA 1P B 63A
Brand: BEMKO
SKU: ABB011BEMK
Price: 22.58 PLN
Availability: BackOrder

Indeks lokalny:

ABB011BEMK

Numer katalogowy:

S-A00-S7-1P-B63

Kod EAN:

5908311361450

Kliknij zdjęcie, aby powiększyć

Producent: BEMKO

Cena:

22,58 zł

gross / szt.

(w tym VAT 23%)

2 tygodnie

Na zamówienie

Ilość szt.

(wielokrotność:

)

Dodaj do zapytania ofertowego

Dodaj do schowka

Drukuj

Zapytaj o produkt

Dane techniczne Dane producenta Opakowania zbiorcze Pliki do pobrania

Dane techniczne

Release characteristic

B
Number of protected poles

1
Rated voltage

230 V
Rated impulse withstand voltage Uimp

4 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

4.5 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

4.5 kA
Frequency

50 ... 60 Hz
Concurrently switching neutral conductor

No
Pollution degree

2
Width in number of modular spacings

1
Degree of protection (IP)

IP20
Connectable conductor cross section multi-wired

5 ... 16 mm²

Number of poles (total)

1
Rated current

63 A
Rated insulation voltage Ui

300 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

4.5 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

4.5 kA
Voltage type

AC
Current limiting class

1
Over voltage category

3
Additional equipment possible

No
Built-in depth

50 mm
Ambient temperature during operating

-5 ... 60 °C
Connectable conductor cross section solid-core

5 ... 25 mm²
