Motor switch GZ1E push-button drive I=6-10A box terminals GZ1E14
local index:
ASN053SCHN
Catalog No:
GZ1E14
EAN code:
3606480567865
Manufacturer:
SCHNEIDER ELECTRIC
Color: Gray
Price:
44,18 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Motor switch GZ1E push-button drive I=6-10A box terminals
Technical data
-
ColorGray
-
PKWIU27.12.22.0
Other technical data
-
Overload release current setting6 ... 10 A
-
With thermal overload protectionYes
-
Switch off techniqueThermomagnetic
-
Rated permanent current Iu10 A
-
Rated operation power at AC-3, 400 V4 kW
-
Type of control elementPush button
-
With integrated auxiliary switchNo
-
Number of poles3
-
Degree of protection (IP)IP20
-
Width44.5 mm
-
Adjustment range undelayed short-circuit release138 ... 138 A
-
Phase failure sensitiveNo
-
Rated operating voltage690 ... 690 V
-
Rated operation power at AC-3, 230 V2.2 kW
-
Type of electrical connection of main circuitScrew connection
-
Device constructionComplete device in housing
-
With integrated under voltage releaseNo
-
Rated short-circuit breaking capacity lcu at 400 V, AC100 kA
-
Height89 mm
-
Depth78 mm
