Motor switch GZ1E push-button drive I=0.25-0.4A box terminals GZ1E03

local index:
ASN034SCHN
Catalog No:
GZ1E03
EAN code:
3606480567797
Price:
40,04 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Accessible 2 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Motor switch GZ1E push-button drive I=0.25-0.4A box terminals

Technical data

  • Color
    Gray
  • PKWIU
    27.12.22.0

Other technical data

  • Overload release current setting
    0.25 ... 0.4 A
  • With thermal overload protection
    Yes
  • Switch off technique
    Thermomagnetic
  • Rated permanent current Iu
    0.4 A
  • Type of control element
    Push button
  • With integrated auxiliary switch
    No
  • Number of poles
    3
  • Degree of protection (IP)
    IP20
  • Width
    44.5 mm
  • Adjustment range undelayed short-circuit release
    5 ... 5 A
  • Phase failure sensitive
    No
  • Rated operating voltage
    690 ... 690 V
  • Type of electrical connection of main circuit
    Screw connection
  • Device construction
    Complete device in housing
  • With integrated under voltage release
    No
  • Rated short-circuit breaking capacity lcu at 400 V, AC
    100 kA
  • Height
    89 mm
  • Depth
    78 mm
