el12
Electrical apparatus
fuses
Other fuses
Miniature motor circuit breaker GB 4A 1P+N GB2CD09
local index:
ABN001SCHN
Catalog No:
GB2CD09
EAN code:
3389110214918
Click on the photo to enlarge
Manufacturer:
SCHNEIDER ELECTRIC
Number of poles:
1
Magnetic tripping current [A]:
52
Rated current [A]:
4
See full description
Price:
90,72 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to cart
Add to clipboard
Print
Ask about the product
Product description
Technical data
Manufacturer details
Product description
Miniature motor circuit breaker GB 4A 1P+N
Technical data
Number of poles
1
Rated current [A]
4
Magnetic tripping current [A]
52
PKWIU
27.12.22.0
Other technical data
Release characteristic
Other
Number of protected poles
1
Rated voltage
250 V
Rated impulse withstand voltage Uimp
4 kV
Voltage type
AC
Current limiting class
3
Over voltage category
3
Additional equipment possible
No
Built-in depth
74 mm
Ambient temperature during operating
-20 ... 60 °C
Connectable conductor cross section solid-core
0.75 ... 6 mm²
Number of poles (total)
2
Rated current
4 A
Rated insulation voltage Ui
250 V
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
3 kA
Frequency
50 ... 60 Hz
Concurrently switching neutral conductor
Yes
Pollution degree
2
Width in number of modular spacings
1
Degree of protection (IP)
IP20
Connectable conductor cross section multi-wired
0.75 ... 4 mm²
Manufacturer details
Manufacturer
Schneider Electric Polska Sp. z o.o.
Address
02-673 Warszawa ul. Konstruktorska 12
Phone number
225844377
E-mail
pawel.wichur@pl.schneider-electric.com
WWW
https://www.schneiderelectric.com
Tax identification number
5220011965
GLN
5900009931556
See more >>
