Miniature motor circuit breaker GB 2A 1P GB2CB07

local index:
ASN073SCHN
Catalog No:
GB2CB07
EAN code:
3389110214611
Manufacturer: SCHNEIDER ELECTRIC
Number of poles: 1
Price:
78,24 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Miniature motor circuit breaker GB 2A 1P

Technical data

  • Number of poles
    1
  • PKWIU
    27.12.22.0

Other technical data

  • Release characteristic
    Other
  • Number of protected poles
    1
  • Rated voltage
    250 V
  • Rated impulse withstand voltage Uimp
    4 kV
  • Voltage type
    AC
  • Current limiting class
    3
  • Over voltage category
    3
  • Additional equipment possible
    No
  • Built-in depth
    74 mm
  • Ambient temperature during operating
    -20 ... 60 °C
  • Connectable conductor cross section solid-core
    0.75 ... 6 mm²
  • Number of poles (total)
    1
  • Rated current
    2 A
  • Rated insulation voltage Ui
    250 V
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
    15 kA
  • Frequency
    50 ... 60 Hz
  • Concurrently switching neutral conductor
    No
  • Pollution degree
    2
  • Width in number of modular spacings
    1
  • Degree of protection (IP)
    IP20
  • Connectable conductor cross section multi-wired
    0.75 ... 4 mm²
