Miniature circuit breaker 6kA C four-pole 25A MCN425E

Místní index:
ABC163HAGE
Katalogové číslo.:
MCN425E
EAN kód:
3250614314148
Výrobce: HAGER
Characteristic: c
Depth [mm]: 70
Number of poles: 4
Cena:
38,27 €
gross / kusů.
(včetně DPH 23%)
Dodání do 3 hodin
do 4 týdnů (pracovní dny)
Vyzvednutí za 1h
Množství kusů.
(vícenásobné:
1
)
Přidat do žádosti o cenovou nabídku
Přidat do schránky
Vytisknout

Popis produktu

Miniature circuit breakers 0.5 - 63 A. Type B and C. Rated short-circuit breaking capacity 6000 A
• rated short-circuit switching capacity: 6000 A, in accordance with PN-EN 60898-1,
• energy limitation class: 3,
• rated operational voltage: 230/400 V AC - single-pole circuit breaker, 400 V AC - multi-pole circuit breaker,
• can be used in DC circuits,
• wide range of accessoriesó
• possibility of connection using vertical and horizontal comb busbars,
• cage terminals: wire up to 25 mm2, strand up to 16 mm2,
• description field with a safety flap,
• degree of protection: IP2X for terminals, IP40 for the device built into the switchgear.

Technické údaje

  • Characteristic
    c
  • Number of poles
    4
  • Rated current [A]
    25
  • Width [mm]
    70
  • Rated short-circuit breaking capacity [kA]
    6
  • Depth [mm]
    70
  • Rated voltage [V]
    230
  • Power dissipation [W]
    12.8
  • Height [mm]
    83
  • PKWIU
    27.12.22.0

Další technické údaje

  • Built-in depth
    70 mm
  • Number of poles (total)
    4
  • Rated current
    25 A
  • Rated insulation voltage Ui
    500 V
  • Voltage type
    AC
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
    10 kA
  • Current limiting class
    3
  • Over voltage category
    3
  • Additional equipment possible
    Yes
  • Degree of protection (IP)
    IP20
  • Connectable conductor cross section multi-wired
    1 ... 25 mm²
  • Release characteristic
    C
  • Number of protected poles
    4
  • Rated voltage
    400 V
  • Rated impulse withstand voltage Uimp
    4 kV
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
    6 kA
  • Frequency
    50 ... 60 Hz
  • Concurrently switching neutral conductor
    No
  • Pollution degree
    2
  • Width in number of modular spacings
    4
  • Ambient temperature during operating
    -25 ... 70 °C
  • Connectable conductor cross section solid-core
    1 ... 35 mm²

Podrobnosti o výrobci

Velkoobjemová balení

Typ obalu Karton Pakiet Paleta
Množství 3 kusů. 36 kusů. 864 kusů.
Hmotnost (kg) 1,270 15,280 366,910
Šířka (m) 0,090 0,310 0,800
Délka (m) 0,080 0,230 1,070
Hloubka (m) 0,220 0,360 1,200
