MCB SLS Selective overcurrent circuit breaker 3P E 50A TS35 HTN350E

Name: MCB SLS Selective overcurrent circuit breaker 3P E 50A TS35
Brand: HAGER
SKU: ABS023HAGE
Price: 1271.21 PLN
Availability: BackOrder

Index local:

ABS023HAGE

Numéro de catalogue:

HTN350E

Code EAN:

3250613303358

MCB SLS Selective overcurrent circuit breaker 3P E 50A TS35

Cliquer sur la photo pour l'agrandir

Producteur: HAGER

Rated frequency [Hz]: 60

Length [mm]: 91

Depth [mm]: 85

Voir la description complète

Prix:

1 271,21 zł

gross / pcs.

(y compris la TVA 23%)

jusqu'à 4 semaines

Sur commande

Quantité pcs.

(plusieurs:

)

Ajouter à la demande de devis

Ajouter au presse-papiers

Imprimer

Renseignez-vous sur le produit

Description du produit Données techniques Détails du fabricant Emballage en vrac Fichiers à télécharger

Description du produit

Selective overcurrent circuit breaker MCB series SLS.

50A,
can be mounted on a TS35 mounting rail or via busbar adapter (distance 40 mm),
tripping characteristic E:
- thermal release 1.05 to 1.20 x IN
- electromagnetic release 5 x 6.25 IN
rated voltage: 230/400 V
contact position indicator
cage terminals:
- solid wire up to 50 mm²
- stranded wire up to 35 mm²

Specifications of the SLS series:< /p>

The selective circuit breaker provides ease of operation of the circuit breaker, high short-circuit resistance (25 kA) and full selectivity for protected standard circuit breakers. For the needs of full integration with the basic protections, special characteristics of the E and Cs trips have been developed, which allows the full use of the protection capabilities of the entire system.

Données techniques

Rated frequency [Hz]

60
Depth [mm]

85
Tightening torque [Nm]

4
Rated insulation voltage [V]

690
Family

SLS
Power dissipation [W]

10
Power loss per pole [W]

6.5
Height [mm]

110
Mechanical durability (number of cycles)

10000
Rated switching voltage [V]

230/400
Max/min value of the AC current of the protection activation

5/6.25 in
storage temperature [°C]

from -25 to 80
Wire cross-section (cord) [mm²]

1.5 - 35
PKWIU

27.12.22.0

Length [mm]

91
Number of poles

3
Installation

On the TH-35 rail
Rated current [A]

50
Level of security

IP20
power loss [W]

19.5
Width [mm]

81
Electrical endurance (number of cycles)

1500
Operating temperature range [°C]

from -25 to 55
Number of modules

4.5
Operating short-circuit breaking current Ics [kA]

12.5
Rated surge voltage [V]

6000
Conductor cross-section (wire) [mm²]

1.5 - 50

Autres données techniques

Release characteristic

E
Rated current

50 A
Rated insulation voltage Ui

690 V
Concurrently switching neutral conductor

No
Over voltage category

4
Rated surge voltage invariability

6 kV
Degree of protection (IP)

IP20

Number of poles

3
Rated voltage

400 V
Rated switching capacity

25 kA
Frequency

50 Hz
Pollution degree

3
Mounting method

DIN rail

Détails du fabricant

Producteur

Hager Electro S.A.S.
Adresse

FR 67215 Obernai 123 boulevard d’Europe Francja
E-mail

wsparcie.klienta@hager.com

Emballage en vrac

Une sorte de paquet	Karton	Pakiet	Paleta	Karton	Pakiet	Paleta
Quantité	1 pcs.	8 pcs.	192 pcs.	1 pcs.	8 pcs.	192 pcs.
poids (kg)	0,995	8,340	223,160	0,995	8,340	223,160
Largeur (m)	0,120	0,310	0,800	0,120	0,310	0,800
Longueur (m)	0,090	0,210	1,050	0,090	0,210	1,050
Profondeur (m)	0,150	0,360	1,200	0,150	0,360	1,200
