MCB Circuit breaker 6kA 1P C 13A QuickConnect MCS113

Indice locale:
ABC203HAGE
Numero di catalogo:
MCS113
Codice EAN:
3250614315176
Produttore: HAGER
Family: MCB
Prezzo:
8,54 €
gross / pezzi
(inclusa IVA 23%)
Consegna in 3 ore
fino a 2 settimane (giorni lavorativi)
Raccolta in 1h
Quantità pezzi
(multiplo:
1
)
Aggiungi agli appunti
Stampa

Descrizione del prodotto

MCB Circuit breaker 6kA 1P C 13A QuickConnect

Dati tecnici

  • Family
    MCB

Altri dati tecnici

  • Built-in depth
    70 mm
  • Number of poles (total)
    1
  • Rated current
    13 A
  • Rated insulation voltage Ui
    500 V
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
    6 kA
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
    6 kA
  • Current limiting class
    3
  • Concurrently switching neutral conductor
    No
  • Pollution degree
    2
  • Width in number of modular spacings
    1
  • Ambient temperature during operating
    -25 ... 70 °C
  • Connectable conductor cross section solid-core
    1 ... 35 mm²
  • Release characteristic
    C
  • Number of protected poles
    1
  • Rated voltage
    400 V
  • Rated impulse withstand voltage Uimp
    4 kV
  • Voltage type
    AC
  • Frequency
    50 ... 60 Hz
  • Flush-mounted installation
    Yes
  • Over voltage category
    3
  • Additional equipment possible
    No
  • Degree of protection (IP)
    IP20
  • Connectable conductor cross section multi-wired
    1 ... 25 mm²
  • Explosion-proof
    No

Imballaggio sfuso

Una specie di pacchetto Karton Pakiet Paleta
Quantità 1 pezzi 12 pezzi 144 pezzi 3456 pezzi
Peso (kg) 0,081 1,050 12,930 333,320
Larghezza (m) 0,018 0,095 0,315 0,800
Lunghezza (m) 0,087 0,080 0,235 1,070
Profondità (m) 0,073 0,225 0,360 1,200
