MCB Circuit breaker 50kA 2P C 10A HMX210

Внутрішній артикул:

ABC063HAGE

№ каталоговий:

HMX210

Код EAN:

3250613231897

Натисни на фото щоб збільшити

Виробник: HAGER

Characteristic: c

Rated frequency [Hz]: 60

Depth [mm]: 70

Дивіться повний опис

Ціна:

1 236,89 zł

gross / шт.

(з ПДВ 23%)

до 10 тижнів

На замовлення

Кількість шт.

(багаторазовий:

)

Додати до запиту на пропозицію

Додати в буфер обміну

Роздрукувати

Запитайте про товар

Опис товару Технічні дані Інформація про виробника Об'ємна упаковка Файли для завантаження

Опис товару

MCB circuit breaker to protect the electrical installation against the effects of short circuits and overloads. It can also be used as a means of protection against electric shock - automatic shutdown in the event of a short-circuit with negligible impedance between the line conductor and the accessible conductive part or the protective conductor.

Технічні дані

Characteristic

c
Depth [mm]

70
Tightening torque [Nm]

3.5 to 5
Rated current [A]

10
Level of security

IP20
power loss [W]

4.47
Width [mm]

53
Height [mm]

90
Mechanical durability (number of cycles)

20000
Rated switching voltage [V]

415
Number of modules

3
Ultimate short-circuit breaking capacity Icu for 230V [kA]

50
Ultimate short-circuit breaking capacity Icu for 400V [kA]

50
Ultimate short-circuit breaking capacity per pole for 400V [kA]

4.5
storage temperature [°C]

from -25 to 80
Rated current correction factor for 2 devices installed side by side

1
Rated surge voltage [V]

6000
Wire cross-section (cord) [mm²]

1.5 - 35
PKWIU

27.12.23.0

Rated frequency [Hz]

60
Number of poles

2
Rated insulation voltage [V]

500
Family

MCB
Power dissipation [W]

3
Power loss per pole [W]

2.23
Connection type

Clamps with alignment system
Electrical endurance (number of cycles)

4000
Operating temperature range [°C]

from -5 to 60
Rated short-circuit breaking capacity Icn [kA]

50
Max/min value of the AC current of the protection activation

7.9/11.9 in
Ultimate short-circuit breaking capacity Icu for 240V [kA]

50
Ultimate short-circuit breaking capacity Icu for 415V [kA]

50
Service short-circuit breaking capacity Ics [%]

50
Supply voltage type

AC
Rated current correction factor for 3 devices installed side by side

0.95
Number of protected poles

2
Conductor cross-section (wire) [mm²]

1.5 - 50

Інші технічні дані

Built-in depth

70 mm
Number of poles (total)

2
Rated current

10 A
Rated insulation voltage Ui

500 V
Voltage type

AC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

50 kA
Current limiting class

3
Over voltage category

3
Additional equipment possible

Yes
Degree of protection (IP)

IP20
Connectable conductor cross section multi-wired

1 ... 50 mm²

Release characteristic

C
Number of protected poles

2
Rated voltage

415 V
Rated impulse withstand voltage Uimp

6 kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

50 kA
Frequency

50 ... 60 Hz
Concurrently switching neutral conductor

No
Pollution degree

3
Width in number of modular spacings

3
Ambient temperature during operating

-25 ... 70 °C
Connectable conductor cross section solid-core

1 ... 70 mm²

Інформація про виробника

Виробник

Hager Electro S.A.S.
Адреса

FR 67215 Obernai 123 boulevard d’Europe Francja
Електронна пошта

wsparcie.klienta@hager.com

Об'ємна упаковка

Свого роду пакет	CT	PK	PF
Кількість	1 шт.	24 шт.	576 шт.
Вага (кг)	0,390	9,295	246,080
Ширина (м)	0,080	0,300	0,800
Довжина (м)	0,050	0,110	0,840
Глибина (м)	0,090	0,360	1,200
