M1UQ02/100A/690 ultra-fast fuse-link 004743214

local index:
ABM734ETIP
Catalog No:
004743214
EAN code:
3838895756507
Manufacturer: ETI POLAM
Rated voltage [V]: 690
Rated current [A]: 100
Power dissipation [W]: 27
Price:
69,15 €
gross / pcs.
(including VAT 23%)
138,30 € gross/kg.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

M-type fuse links are designed for mounting in standard industrial fuse bases (e.g. PK) or fuse switch disconnectors.

Technical data

  • Rated voltage [V]
    690
  • Power dissipation [W]
    27
  • Rated short-circuit capacity [kA]
    200
  • Rated current [A]
    100
  • Weight [g]
    500
  • PKWIU
    27.12.21.0

Other technical data

  • Rated current
    100 A
  • Type of fuse status indicator
    Top fuse status indicator
  • Utilization category
    aR (accompanied semiconductor protection)

Bulk packaging

A kind of package Pudełko Pudełko
Quantity 3 pcs. 24 pcs.
Weight (kg) 1,280 -
Volume (m3) 0,001 -
Width (m) 0,140 -
Length (m) 0,143 -
Depth (m) 0,070 -
