Knife fuse link NH000 gG with central indicator 16A 500V LNH0016M

local index:
ABI464HAGE
Catalog No:
LNH0016M
EAN code:
3250614120671
Manufacturer: HAGER
Characteristic: gG
Length [mm]: 51
DC operating voltage [V]: 0/500/550
Price:
3,69 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Knife fuse insert:

  • double indicator,
  • non-insulated handle,
  • fuse characteristics: gG,< /li>
  • trigger characteristics: gG.

Technical data

  • Characteristic
    gG
  • DC operating voltage [V]
    0/500/550
  • power loss [W]
    1.8
  • Fuse link size
    NH000
  • Rated switching voltage [V]
    0/500/550
  • PKWIU
    27.12.21.0
  • Length [mm]
    51
  • Rated current [A]
    16
  • Width [mm]
    21
  • Height [mm]
    79
  • Rated short-circuit breaking capacity Icn [kA]
    120

Other technical data

  • Voltage type
    AC
  • Rated switching capacity
    120 kA
  • Type of fuse status indicator
    Combination fuse status indicator
  • Rated current
    16 A
  • Utilization category
    gL/gG (ochrona instalacji elektroenergetycznych przed skutk. zwarć i przeciążeń)
  • Insulated metal gripping lugs (IMGL)
    No

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 3 pcs. 108 pcs. 3456 pcs.
Weight (kg) 0,118 0,370 13,985 470,520
Width (m) 0,021 0,070 0,285 0,800
Length (m) 0,079 0,065 0,150 1,500
Depth (m) 0,051 0,085 0,395 1,200
