The slow-blow fuse link is the right choice if you want to protect your devices against a momentary voltage spike. Used where there is a short-term overload (e.g. the moment of connecting a new power supply device to the network. A fuse with a slow-blow fuse link can withstand a momentary increase in voltage and not turn off the entire network, despite a temporary overload. This is due to the loop located in the insert, which can accumulate energy for some time.

Characteristic

gG
Rated current [A]

50
Size

NH1C
Indicator

KOMBI double indicator

Rated voltage [V]

500
Type

NH
Short-circuit breaking capacity [kA]

120
PKWIU

27.12.21.0

Other technical data

Voltage type

AC
Rated switching capacity

120 kA
Type of fuse status indicator

Combination fuse status indicator

Rated current

50 A
Utilization category

gL/gG (ochrona instalacji elektroenergetycznych przed skutk. zwarć i przeciążeń)

Manufacturer details

Manufacturer

ETI-POLAM Sp. z o.o.
Address

06-100 Pułtusk Jana Pawła II 18
E-mail

etipolam@etipolam.com.pl
WWW

https://www.etipolam.com.pl
Tax identification number

5681370113
GLN

5909000467408

A kind of package	Pudełko	Pudełko
Quantity	3 pcs.	45 pcs.
Weight (kg)	0,750	-
Volume (m3)	0,001	-
Width (m)	0,139	0,295
Length (m)	0,150	0,235
Depth (m)	0,065	0,245
