Industrial fuse link WT-00C/gG 63A 500 - delayed 004111436

local index:
ABM073ETIP
Catalog No:
004111436
EAN code:
5904722990951
Manufacturer: ETI POLAM
Model: WT-00C/gG 63A 500
Rated voltage [V]: 500
Rated current [A]: 63
Price:
49,42 €
gross / pkg.
(including VAT 23%)
4,12 € gross/pcs.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Industrial fuse links are designed to protect electrical installations against the effects of short circuits and overloads. Fuse-links with fast gF characteristics are intended for use in rural power lines - where, due to scattered buildings, small cross-sections of wires, low short-circuit powers of transformers, short-circuit currents may be small, and thus their tripping time by the fuse-link delayed - long. The operation of the gG slow-blow fuse-link at small overloads is slower than that of fast-acting fuse-links, and very fast in the event of a short-circuit. They have a trip indicator and are mounted in fuse bases with an insulating holder. Insulation class C-VDE 0110.

Technical data

  • Model
    WT-00C/gG 63A 500
  • Rated current [A]
    63
  • Type
    Industrial porcelain fuse link
  • PKWIU
    27.12.21.0
  • Rated voltage [V]
    500
  • Pieces in the package
    12
  • Application
    Securing electrical devices and installations

Other technical data

  • Voltage type
    AC
  • Rated switching capacity
    115 kA
  • Type of fuse status indicator
    Top fuse status indicator
  • Rated current
    63 A
  • Utilization category
    gL/gG (ochrona instalacji elektroenergetycznych przed skutk. zwarć i przeciążeń)
