Illuminated yellow flush push-button, 1 NO contact, nickel-plated ring SP22-KLG-10-24-LED\AC/DC
local index:
AKS038SPAM
Catalog No:
SP22-KLG-10-24-LED\AC/DC
EAN code:
5907723080348
Price:
19,13 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Illuminated yellow flush push-button, 1 NO contact, nickel-plated ring
Technical data
-
ColorYellow
-
Continuous current [A]10
-
Accurate colorYellow
-
Rated insulation voltage [V]500
-
Level of securityIP65
Other technical data
-
Number of command positions1
-
Colour buttonYellow
-
Hole diameter22 mm
-
Height opening22 mm
-
Switching function latchingNo
-
Supply voltage lamp24 V
-
Number of contacts as normally closed contact0
-
Type of electric connectionScrew connection
-
Material front ringPlastic
-
Degree of protection (IP)IP65
-
Type of buttonFlat
-
Construction type lensRound
-
Width opening22 mm
-
Suitable for illuminationYes
-
Spring-returnYes
-
Number of contacts as normally open contact1
-
Number of contacts as change-over contact0
-
With front ringYes
-
Colour front ringGrey
