Illuminated white concealed button 1 NO contact

Click on the photo to enlarge

SPAMEL

Illuminated white concealed button 1 NO contact ST22-KLB-10-24-LED\AC/DC

Name: Illuminated white concealed button 1 NO contact
Brand: SPAMEL
SKU: AKS963SPAM
Price: 24.44 PLN

local index:

AKS963SPAM

Catalog No:

ST22-KLB-10-24-LED\AC/DC

EAN code:

5907723016040

Price:

24,44 €

gross / pcs.

including VAT 23%

Availability:

up to 2 weeks (business days)

Delivery:

From 3,69 € (prepaid courier) Details

Quantity:

Goods at a promotional price can only be purchased in the quantity available in stock

pcs.

Delivery methods:

details

Payment methods:

details

Go to section:

Product description Technical data

Product description

Illuminated white concealed button 1 NO contact

Report an error

Technical data

Color

White
Continuous current [A]

10
Accurate color

White

Rated insulation voltage [V]

500
Level of security

IP65

Other technical data

Number of command positions

1
Colour button

White
Hole diameter

22 mm
Height opening

22 mm
Switching function latching

no
Supply voltage lamp

24 V
Number of contacts as normally closed contact

0
Type of electric connection

Screw connection
Material front ring

Plastic
Degree of protection (IP)

IP65

Type of button

Flat
Construction type lens

Round
Width opening

22 mm
Suitable for illumination

yes
Spring-return

yes
Number of contacts as normally open contact

1
Number of contacts as change-over contact

0
With front ring

yes
Colour front ring

Grey
