iCT50-40-04-230 modular contactor 40A 4NC 50Hz 220/240 VAC A9C20847

local index:
ATA213SCHN
Catalog No:
A9C20847
EAN code:
3606480375125
Manufacturer: SCHNEIDER ELECTRIC
AC control voltage [V]: 220/240
Price:
104,89 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
2 weeks
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

iCT50-40-04-230 modular contactor 40A 4NC 50Hz 220/240 VAC

Technical data

  • AC control voltage [V]
    220/240
  • PKWIU
    27.12.24.0

Other technical data

  • Rated operating voltage
    400 ... 400 V
  • Kategoria użytkowania
    7
  • Voltage type (operating voltage)
    AC
  • Number of contacts as normally open contact
    0
  • Max. incandescent lamp load
    15750 W
  • Max. load fluorescent lamp (Duo circuit)
    11400 VA
  • Slider for hand switch
    No
  • Additional equipment possible
    Yes
  • Rated operation current
    40 A
  • Rated excitation voltage
    220 ... 240 V
  • Voltage type (excitation voltage)
    AC
  • Number of contacts as normally closed contact
    4
  • Max. load fluorescent lamp
    7200 VA
  • Max. load fluorescent lamp (parallel compensated)
    7200 VA
  • Built-in depth
    43.5 mm
  • Degree of protection (IP)
    IP20
