Glass fuse 5x20mm FF 250V 5A L520FFG05-000

local index:
ABI083HAGE
Catalog No:
L520FFG05-000
EAN code:
3250614126581
Manufacturer: HAGER
Rated current [A]: 5
power loss [W]: 1.8
Fuse link size: 5 x 20
Price:
1,67 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Glass fuse link superfast:

  • 5A,
  • tripping characteristics: superflink (FF),
  • size fuse link: 5 x 20.

Technical data

  • Rated current [A]
    5
  • Fuse link size
    5 x 20
  • PKWIU
    27.12.21.0
  • power loss [W]
    1.8
  • Rated switching voltage [V]
    250

Other technical data

  • Size
    Other
  • Rated operating frequency
    50 ... 60 Hz
  • Breaking capacity
    0.3 kA
  • Voltage type
    AC
  • Release characteristic
    Other

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 10 pcs. 200 pcs. 40000 pcs.
Weight (kg) 0,001 0,011 0,230 71,000
Width (m) 0,005 0,021 0,045 0,800
Length (m) 0,005 0,006 0,062 0,420
Depth (m) 0,020 0,051 0,080 1,200
