Ex9BP 1P DC150V C16 DC overcurrent circuit breaker 10 kA, for photovoltaic applications, C-characteristic, 16 A, 150 V DC, 1-pole 109968

Name: Ex9BP 1P DC150V C16 DC overcurrent circuit breaker 10 kA, for photovoltaic applications, C-characteristic, 16 A, 150 V DC, 1-pole
Brand: NOARK
SKU: ABC030NOAR
Price: 39.70 PLN
Availability: BackOrder

Index local:

ABC030NOAR

Numéro de catalogue:

109968

Code EAN:

8592765099686

Ex9BP 1P DC150V C16 DC overcurrent circuit breaker 10 kA, for photovoltaic applications, C-characteristic, 16 A, 150 V DC, 1-pole

Cliquer sur la photo pour l'agrandir

Producteur: NOARK

Prix:

39,70 zł

gross / pcs.

(y compris la TVA 23%)

2 semaines

Sur commande

Quantité pcs.

(plusieurs:

)

Ajouter à la demande de devis

Ajouter au presse-papiers

Imprimer

Renseignez-vous sur le produit

Données techniques Détails du fabricant

Données techniques

Autres données techniques

Release characteristic

C
Number of protected poles

1
Rated voltage

150 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

10 kA
Current limiting class

3
Concurrently switching neutral conductor

No
Pollution degree

3
Width in number of modular spacings

1
Degree of protection (IP)

IP20

Number of poles (total)

1
Rated current

16 A
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

10 kA
Voltage type

DC
Do instalacji podtynkowych

Yes
Over voltage category

3
Additional equipment possible

Yes
Built-in depth

72 mm
