Ex9BP 1P DC150V C10 DC overcurrent circuit breaker 10 kA, for photovoltaic applications, C-characteristic, 10 A, 150 V DC, 1-pole 109967

Name: Ex9BP 1P DC150V C10 DC overcurrent circuit breaker 10 kA, for photovoltaic applications, C-characteristic, 10 A, 150 V DC, 1-pole
Brand: NOARK
SKU: ABC004NOAR
Price: 39.70 PLN
Availability: BackOrder

Índice local:

ABC004NOAR

Número de catálogo:

109967

Código EAN:

8592765099679

Ex9BP 1P DC150V C10 DC overcurrent circuit breaker 10 kA, for photovoltaic applications, C-characteristic, 10 A, 150 V DC, 1-pole

Haga clic en la foto para ampliar

Fabricante: NOARK

Precio:

39,70 zł

gross / uds.

(IVA incluido 23%)

2 semanas

Por encargo

Cantidad uds.

(múltiple:

)

Añadir a solicitud de presupuesto

Añadir al portapapeles

Imprimir

Pregunta por el producto

Datos técnicos Detalles del fabricante

Datos técnicos

Otros datos técnicos

Release characteristic

C
Number of protected poles

1
Rated voltage

150 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

10 kA
Current limiting class

3
Concurrently switching neutral conductor

No
Pollution degree

3
Width in number of modular spacings

1
Degree of protection (IP)

IP20

Number of poles (total)

1
Rated current

10 A
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

10 kA
Voltage type

DC
Do instalacji podtynkowych

Yes
Over voltage category

3
Additional equipment possible

Yes
Built-in depth

72 mm
