Ex9B125 3P C100A Overcurrent breaker 20 kA, characteristic C, 100 A, 3 pole 102792

Name: Ex9B125 3P C100A Overcurrent breaker 20 kA, characteristic C, 100 A, 3 pole
Brand: NOARK
SKU: ABC037NOAR
Price: 558.08 PLN
Availability: BackOrder

local index:

ABC037NOAR

Catalog number:

102792

EAN code:

8592765027931

Ex9B125 3P C100A Overcurrent breaker 20 kA, characteristic C, 100 A, 3 pole

Click on the photo to enlarge

Manufacturer: NOARK

Price:

558,08 zł

gross / pcs.

(including VAT 23%)

up to 4 weeks

On request

Quantity pcs.

(multiplicity:

)

Add to inquiry

Add to clipboard

Ask about the product

Technical data Manufacturer details

Technical data

Other technical data

Release characteristic

C
Number of protected poles

3
Rated voltage

400 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

15 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

20 kA
Frequency

50 ... 60 Hz
Do instalacji podtynkowych

Yes
Over voltage category

3
Additional equipment possible

Yes
Built-in depth

75 mm

Number of poles (total)

3
Rated current

100 A
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

15 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

20 kA
Voltage type

AC
Current limiting class

3
Concurrently switching neutral conductor

No
Pollution degree

2
Width in number of modular spacings

4.5
Degree of protection (IP)

IP20
