DIVUQ100A ultra-fast fuse-link 004324002

local index:
ABM019ETIP
Catalog No:
004324002
EAN code:
5904722914872
Manufacturer: ETI POLAM
Characteristic: gR
DC rated voltage [V]: 315
Rated current [A]: 100
Price:
24,64 €
gross / pcs.
(including VAT 23%)
224,00 € gross/kg.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

System D inserts are used in E16, E27, E33, R 1 1/4'', R2'' fuse sockets.

Technical data

  • Characteristic
    gR
  • Rated current [A]
    100
  • Rated short-circuit capacity [kA]
    ~50/-8
  • PKWIU
    27.12.21.0
  • DC rated voltage [V]
    315
  • Weight [g]
    110
  • AC rated voltage [V]
    500

Other technical data

  • Construction size
    DIV
  • Rated voltage
    500 V
  • Utilization category
    gR (general purpose semiconductor protection)
  • Rated current
    100 A
  • Colour code
    Red
  • Release characteristic
    Super fast (FF)

Bulk packaging

A kind of package Pudełko Pudełko
Quantity 3 pcs. 48 pcs.
Weight (kg) 0,350 -
Volume (m3) 0,000 -
Width (m) 0,038 -
Length (m) 0,113 -
Depth (m) 0,066 -
