DIIUQ6A ultra-fast fuse-link 004322003

local index:
ABI508ETIP
Catalog No:
004322003
EAN code:
5904722914773
Manufacturer: ETI POLAM
Characteristic: gR
DC rated voltage [V]: 315
Rated current [A]: 6
Price:
4,86 €
gross / pcs.
(including VAT 23%)
180,00 € gross/kg.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

System D inserts are used in E16, E27, E33, R 1 1/4'', R2'' fuse sockets.

Technical data

  • Characteristic
    gR
  • Rated current [A]
    6
  • Weight [g]
    27
  • AC rated voltage [V]
    500
  • DC rated voltage [V]
    315
  • Power dissipation [W]
    3.2
  • Rated short-circuit capacity [kA]
    ~50/-8
  • PKWIU
    27.12.21.0

Other technical data

  • Construction size
    DII
  • Rated voltage
    500 V
  • Utilization category
    gR (general purpose semiconductor protection)
  • Rated current
    6 A
  • Colour code
    Green
  • Release characteristic
    Super fast (FF)

Bulk packaging

A kind of package Pudełko Pudełko Pudełko
Quantity 1 pcs. 5 pcs. 500 pcs.
Weight (kg) 0,160 - -
Volume (m3) 0,000 - -
Width (m) 0,023 - -
Length (m) 0,110 - -
Depth (m) 0,050 - -
