DC circuit breaker ETIMAT10 2P 6kA B 40A DC 002128720

Name: DC circuit breaker ETIMAT10 2P 6kA B 40A DC
Brand: ETI POLAM
SKU: ABB012ETIP
Price: 62.66 PLN

local index:

ABB012ETIP

Catalog No:

002128720

EAN code:

3838895421641

DC circuit breaker ETIMAT10 2P 6kA B 40A DC

Click on the photo to enlarge

Manufacturer: ETI POLAM

Characteristic: b

Number of poles: 2

Rated current [A]: 20

See full description

Price:

62,66 €

gross / pcs.

(including VAT 23%)

Delivery in 3h

up to 2 weeks (business days)

Pickup in 1h

Quantity pcs.

(multiplicity:

)

Add to clipboard

Ask about the product

Product description Technical data Manufacturer details Bulk packaging Files to download

Product description

ETIMAT 10 DC overcurrent circuit breakers are used to protect DC installations. For voltages up to 220 V, a 1-pole switch is used, for higher voltages (up to 440 V) - a 2-pole switch, but with series-connected poles. When connecting ETIMAT 10 DC circuit breakers, pay attention to their polarity. Note: Two 1-pole circuit breakers cannot be used instead of a 2-pole DC circuit breaker.

Technical data

Characteristic

b
Rated current [A]

20
PKWIU

27.12.22.0

Number of poles

2
Rated short-circuit breaking capacity [A]

6000

Other technical data

Built-in depth

68 mm
Number of poles (total)

2
Rated current

40 A
Voltage type

DC
Current limiting class

3
Width in number of modular spacings

2
Ambient temperature during operating

-25 ... 55 °C

Release characteristic

B
Number of protected poles

2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

6 kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

6 kA
Additional equipment possible

Yes
Degree of protection (IP)

IP20

Manufacturer details

Manufacturer

ETI-POLAM Sp. z o.o.
Address

06-100 Pułtusk Jana Pawła II 18
E-mail

etipolam@etipolam.com.pl
WWW

https://www.etipolam.com.pl
Tax identification number

5681370113
GLN

5909000467408

Bulk packaging

A kind of package	Pudełko	Pudełko
Quantity	1 pcs.	54 pcs.
Weight (kg)	0,260	-
Volume (m3)	0,000	-
Width (m)	0,038	-
Length (m)	0,078	-
Depth (m)	0,092	-
