Pros:
→ smaller dimensions of D0 fuse-links, thanks to which we have more space in the switchgear,
→ low power and energy losses,
→ low temperature rise,
→ high short-circuit current limiting capacity,
→ stability of current-time characteristics and full selectivity of operation,
→ selective cooperation with overcurrent breakers,
→ 9 mm socket design,
→ low height for installation in shallow distribution boxes,
→ easy swap of DO1 and DO2 sockets,
→ possibility of using VLDO1 and STV DO2 fuse switch disconnectors.

Characteristic

gG
Rated current [A]

100
Dimensions [mm]

24.4
Rated short-circuit capacity [kA]

50 (AC) cos = 0.1 / 8kA (DC) T=15ms
PKWIU

27.12.21.0

DC rated voltage [V]

250
Weight [g]

35
Compliance with standards

PN-IEC 269, EN 60269, DIN VDE 0636
AC rated voltage [V]

400

Other technical data

Construction size

D03
Rated voltage

400 V
Utilization category

gL/gG (ochrona instalacji elektroenergetycznych przed skutk. zwarć i przeciążeń)

Rated current

100 A
Colour code

Red

A kind of package	Pudełko	Pudełko
Quantity	10 pcs.	400 pcs.
Weight (kg)	0,400	-
Volume (m3)	0,000	-
Width (m)	0,050	-
Length (m)	0,120	-
Depth (m)	0,050	-
