Pros:
→ smaller dimensions of D0 fuse-links, thanks to which we have more space in the switchgear,
→ low power and energy losses,
→ low temperature rise,
→ high short-circuit current limiting capacity,
→ stability of current-time characteristics and full selectivity of operation,
→ selective cooperation with overcurrent breakers,
→ 9 mm socket design,
→ low height for installation in shallow distribution boxes,
→ easy swap of DO1 and DO2 sockets,
→ possibility of using VLDO1 and STV DO2 fuse switch disconnectors.

Characteristic

gG
Rated current [A]

13
Weight [g]

6
Compliance with standards

PN-IEC 269, EN 60269, DIN VDE 0636
AC rated voltage [V]

400

DC rated voltage [V]

250
Pieces in the package

10
Dimension A [mm]

7.3
Rated short-circuit capacity [kA]

50 (AC) cos = 0.1 / 8kA (DC) T=15ms
PKWIU

27.12.21.0

Other technical data

Construction size

D01
Rated voltage

400 V
Utilization category

gL/gG (ochrona instalacji elektroenergetycznych przed skutk. zwarć i przeciążeń)

Rated current

13 A
Colour code

Black

A kind of package	Pudełko	Pudełko
Quantity	1 pkg.	50 pkg.
Weight (kg)	0,065	-
Volume (m3)	0,000	-
Width (m)	0,040	-
Length (m)	0,060	-
Depth (m)	0,024	-
