Cylindrical fuse link CH22x58 aM 20A 002641011
local index:
ABI062ETIP
Catalog No:
002641011
EAN code:
3838895581338
Price:
6,06 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Application - Cylindrical CH fuse links (with gG and aM characteristics) are used to protect electrical devices and installations against the effects of short circuits and overloads. Cylindrical fuse links do not have an indicator.
Technical data
-
CharacteristicaM
-
TypeCH
-
Dimensions [mm]22 x 58
-
AC rated voltage [V]690
-
Rated current [A]20
-
SizeCH22
-
Short-circuit breaking capacity [kA]52
-
PKWIU27.12.21.0
Other technical data
-
Size22x58 mm
Bulk packaging
| A kind of package | Pudełko | Pudełko |
| Quantity | 10 pcs. | 500 pcs. |
| Weight (kg) | 0,520 | - |
| Volume (m3) | 0,000 | - |
| Width (m) | 0,110 | - |
| Length (m) | 0,120 | - |
| Depth (m) | 0,025 | - |
