Complete two-position rotary drive with a yellow tongue ST22-P.G\.

local index:
AKS117SPAM
Catalog No:
ST22-P.G\.
EAN code:
5907723049345
Manufacturer: SPAMEL
Color: Yellow
Housing material: Plastic
Rated current [A]: 10
Price:
7,86 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Complete two-position rotary drive with a yellow tongue

Technical data

  • Color
    Yellow
  • Rated current [A]
    10
  • Accurate color
    Yellow
  • Housing material
    Plastic
  • Level of security
    IP65

Other technical data

  • Number of switch positions
    2
  • Suitable for illumination
    No
  • Construction type lens
    Round
  • Width opening
    29 mm
  • Switching function latching
    Yes
  • With front ring
    Yes
  • Colour front ring
    Grey
  • Type of control element
    Other
  • Colour control element
    Yellow
  • Hole diameter
    22 mm
  • Height opening
    29 mm
  • Spring-return
    No
  • Material front ring
    Plastic
  • Degree of protection (IP), front side
    IP65
