Circuit breaker G103 C06, 10kA 674907

Name: Circuit breaker G103 C06, 10kA
Brand: ABB
SKU: ABC083ABBQ
Price: 83.97 PLN
Availability: InStock

Lokaler Index:

ABC083ABBQ

Katalognummer:

674907

EAN-Code:

5413656749073

Klicken Sie auf das Foto, um es zu vergrößern

Hersteller: ABB

Characteristic: c

Siehe vollständige Beschreibung

Preis:

83,97 zł

gross / stk.

(inklusive MwSt 23%)

Zugänglich 1 stk.

Menge stk.

(mehrere:

1

)

Zur Angebotsanfrage hinzufügen

Zur Zwischenablage hinzufügen

Drucken

Fragen Sie nach dem Produkt

Produktbeschreibung Technische Daten Hersteller-Details

Produktbeschreibung

Circuit breaker G103 C06, 10kA

Release characteristic

C
Number of protected poles

3
Rated voltage

415 V
Rated impulse withstand voltage Uimp

6 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

15 kA
Frequency

50 ... 60 Hz
Do instalacji podtynkowych

No
Over voltage category

3
Additional equipment possible

Yes
Built-in depth

44 mm
Ambient temperature during operating

-25 ... 70 °C
Connectable conductor cross section solid-core

1 ... 35 mm²

Number of poles (total)

3
Rated current

6 A
Rated insulation voltage Ui

500 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

30 kA
Voltage type

AC
Current limiting class

3
Concurrently switching neutral conductor

No
Pollution degree

2
Width in number of modular spacings

3
Degree of protection (IP)

IP20
Connectable conductor cross section multi-wired

0.75 ... 25 mm²
