ETIMAT10 1P+N 10kA C 32A - Overcurrent circuit breaker. Application - Overcurrent circuit breakers are used as protection of electrical installations in residential, public and industrial buildings. Pros: → high short-circuit capacity, → possibility of mounting auxiliary contacts, → meet the requirements of the main circuit breaker.
Technical data
Characteristic
c
Rated voltage [V]
230
Rated current [A]
32
Mechanical durability
20 thousand shifts
Rated short-circuit capacity [kA]
10
PKWIU
27.12.22.0
Number of poles
2
Case
Non-flammable, temperature-resistant material Gray color RAL 7035
Working temperature [°C]
from -25 to +50
Weight [g]
227
Insulation voltage [V]
500
Other technical data
Built-in depth
68 mm
Number of poles (total)
2
Rated current
32 A
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10 kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
15 kA
Current limiting class
3
Over voltage category
3
Additional equipment possible
Yes
Degree of protection (IP)
IP20
Connectable conductor cross section multi-wired
1 ... 25 mm²
Release characteristic
C
Number of protected poles
1
Rated insulation voltage Ui
500 V
Voltage type
Other
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
