Circuit breaker C 80A 3-pole 18731

Name: Circuit breaker C 80A 3-pole
Brand: SCHNEIDER ELECTRIC
SKU: ABC378SCHN
Price: 1161.72 PLN
Availability: BackOrder

Índice local:

ABC378SCHN

Número de catálogo:

18731

Código EAN:

3303430187318

Haga clic en la foto para ampliar

Fabricante: SCHNEIDER ELECTRIC

Characteristic: c

Ver descripción completa

Precio:

1 161,72 zł

gross / uds.

(IVA incluido 23%)

2 semanas

Por encargo

Cantidad uds.

(múltiple:

)

Añadir a solicitud de presupuesto

Añadir al portapapeles

Imprimir

Pregunta por el producto

Descripción del producto Datos técnicos Detalles del fabricante Archivos para descargar

Descripción del producto

Circuit breaker C 80A 3-pole

Release characteristic

C
Number of protected poles

3
Rated voltage

415 V
Rated impulse withstand voltage Uimp

8 kV
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

36 kA
Frequency

50 ... 60 Hz
Over voltage category

4
Additional equipment possible

Yes
Built-in depth

47 mm
Ambient temperature during operating

-30 ... 70 °C
Connectable conductor cross section solid-core

16 ... 70 mm²

Number of poles (total)

3
Rated current

80 A
Rated insulation voltage Ui

690 V
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

70 kA
Voltage type

AC/DC
Concurrently switching neutral conductor

No
Pollution degree

3
Width in number of modular spacings

4.5
Degree of protection (IP)

IP20
Connectable conductor cross section multi-wired

10 ... 50 mm²
