Click on the photo to enlarge

SCHNEIDER ELECTRIC

Circuit breaker C 25A 4-pole 18652

local index:
ABC421SCHN
Catalog No:
18652
EAN code:
3303430186526
Price:
232,46 €
gross / pcs.
including VAT 23%
Availability:
2 weeks
Delivery:
From 3,71 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pcs.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details

Product description

Circuit breaker C 25A 4-pole

Technical data

  • Characteristic
    c

Other technical data

  • Release characteristic
    C
  • Number of protected poles
    4
  • Rated voltage
    400 V
  • Rated impulse withstand voltage Uimp
    8 kV
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
    25 kA
  • Frequency
    50 ... 60 Hz
  • Over voltage category
    4
  • Additional equipment possible
    yes
  • Built-in depth
    47 mm
  • Ambient temperature during operating
    -30 ... 70 °C
  • Connectable conductor cross section solid-core
    1.5 ... 50 mm²
  • Number of poles (total)
    4
  • Rated current
    25 A
  • Rated insulation voltage Ui
    690 V
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
    50 kA
  • Voltage type
    AC/DC
  • Concurrently switching neutral conductor
    yes
  • Pollution degree
    3
  • Width in number of modular spacings
    6
  • Degree of protection (IP)
    IP20
  • Connectable conductor cross section multi-wired
    1 ... 35 mm²
