Circuit breaker -B80-3 B 80A 3-pole A9N18349

Name: Circuit breaker -B80-3 B 80A 3-pole
Brand: SCHNEIDER ELECTRIC
SKU: ABB105SCHN
Price: 168.67 PLN

Indeks lokalny:

ABB105SCHN

Nr katalogowy:

A9N18349

Kod EAN:

3606480379239

Kliknij zdjęcie, aby powiększyć

Producent: SCHNEIDER ELECTRIC

Rated current [A]: 80

Zobacz cały opis

Cena:

168,67 €

gross / szt.

(w tym VAT 23%)

Dostawa do 3h

2 tygodnie

Odbiór za 1h

Ilość szt.

(wielokrotność:

1

)

Dodaj do schowka

Drukuj

Zapytaj o produkt

Opis produktu Dane techniczne Dane producenta Pliki do pobrania

Opis produktu

Circuit breaker -B80-3 B 80A 3-pole

Release characteristic

B
Number of protected poles

3
Rated voltage

400 V
Rated impulse withstand voltage Uimp

6 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

10 kA
Frequency

50 ... 60 Hz
Concurrently switching neutral conductor

No
Pollution degree

3
Width in number of modular spacings

4.5
Degree of protection (IP)

IP20
Connectable conductor cross section multi-wired

1 ... 35 mm²

Number of poles (total)

3
Rated current

80 A
Rated insulation voltage Ui

500 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

20 kA
Voltage type

AC
Current limiting class

3
Over voltage category

4
Additional equipment possible

Yes
Built-in depth

44 mm
Ambient temperature during operating

-25 ... 70 °C
Connectable conductor cross section solid-core

1.5 ... 50 mm²
