Circuit breaker 1-pole G61 C50 1P 50A 6kA 674610

Name: Circuit breaker 1-pole G61 C50 1P 50A 6kA
Brand: ABB
SKU: ABC065ABBQ
Price: 4.91 PLN
Availability: InStock

local index:

ABC065ABBQ

Catalog No:

674610

EAN code:

5413656746102

Circuit breaker 1-pole G61 C50 1P 50A 6kA

Click on the photo to enlarge

Manufacturer: ABB

Rated current [A]: 50

See full description

Outlet

Stan produktu: Towar jest fabrycznie nowy, nieuszkodzony. Może nosić ślady długiego magazynowania.

Opakowanie: Towar może zostać dostarczony w opakowaniu zastępczym lub w lekko uszkodzonym oryginalnym opakowaniu.

Dostępność: Tylko w ilości dostępnej na magazynie.

Outlet

Price:

4,91 €

gross / pcs.

(including VAT 23%)

The lowest price from 30 days before the reduction: 16,16 € gross -11,25 €

Base price: 14,70 € gross

Accessible 5 pcs.

Quantity pcs.

(multiplicity:

1

)

Add to clipboard

Print

Ask about the product

Product description Technical data Manufacturer details

Product description

Current circuit breaker G61 C50 GE

Installation circuit breaker overcurrent single phase.

It is used to protect cables and receivers against overloads and short circuits in installations and devices.

Mounting on DIN 35 mm rail.

Operating characteristics: C

Maximum current: 50A

Rated voltage: 230 V

Breakdown current: 6000 A

Protection: IP 20

Sealable lever .

Rated frequency: 50Hz

Technical data

Rated current [A]

50

PKWIU

31.20.22-30.94

Other technical data

Release characteristic

C
Number of protected poles

1
Rated voltage

415 V
Rated impulse withstand voltage Uimp

6 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

3 kA
Frequency

50 ... 60 Hz
Do instalacji podtynkowych

No
Over voltage category

3
Additional equipment possible

Yes
Built-in depth

44 mm
Ambient temperature during operating

-25 ... 70 °C
Connectable conductor cross section solid-core

1 ... 35 mm²

Number of poles (total)

1
Rated current

50 A
Rated insulation voltage Ui

500 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

10 kA
Voltage type

AC
Current limiting class

3
Concurrently switching neutral conductor

No
Pollution degree

2
Width in number of modular spacings

1
Degree of protection (IP)

IP20
Connectable conductor cross section multi-wired

0.75 ... 25 mm²
