Circuit breaker 1-pole G61 C03 1P 3A 6kA 674599

Name: Circuit breaker 1-pole G61 C03 1P 3A 6kA
Brand: ABB
SKU: ABC054ABBQ
Price: 3.12 PLN
Availability: InStock

local index:

ABC054ABBQ

Catalog No:

674599

EAN code:

5413656745990

Circuit breaker 1-pole G61 C03 1P 3A 6kA

Click on the photo to enlarge

Manufacturer: ABB

Rated current [A]: 3

See full description

Outlet

Stan produktu: Towar jest fabrycznie nowy, nieuszkodzony. Może nosić ślady długiego magazynowania.

Opakowanie: Towar może zostać dostarczony w opakowaniu zastępczym lub w lekko uszkodzonym oryginalnym opakowaniu.

Dostępność: Tylko w ilości dostępnej na magazynie.

Outlet

Price:

3,12 €

gross / pcs.

(including VAT 23%)

The lowest price from 30 days before the reduction: 3,12 € gross

Base price: 11,39 € gross

Accessible 42 pcs.

Quantity pcs.

(multiplicity:

1

)

Add to clipboard

Print

Ask about the product

Product description Technical data Manufacturer details

Product description

GE Redline Circuit Breaker G61 C3 6kA

Rated Current In (A) 3
Rated AC voltage Un (V) 240/415
Minimum operating voltage UBmin (V) 12
Trigger characteristics C
Energy limitation class 3
Mechanical/connective durability (cycles) 20000/10000
Climatic resistance according to IEC 60068 - 2 95 % RH at 55 °C
Cable cross sections (mm2) 25-35
Pole configuration 1, 1+N, 2, 3, 3+N, 4
Weight (g/mod) 120

Technical data

Rated current [A]

3

PKWIU

31.20.22-30.94

Other technical data

Release characteristic

C
Number of protected poles

1
Rated voltage

415 V
Rated impulse withstand voltage Uimp

6 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

6 kA
Frequency

50 ... 60 Hz
Do instalacji podtynkowych

No
Pollution degree

3
Width in number of modular spacings

1
Degree of protection (IP)

IP20
Connectable conductor cross section multi-wired

0.75 ... 25 mm²

Number of poles (total)

1
Rated current

3 A
Rated insulation voltage Ui

500 V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

6 kA
Voltage type

AC
Current limiting class

3
Concurrently switching neutral conductor

No
Additional equipment possible

Yes
Built-in depth

44 mm
Ambient temperature during operating

-25 ... 70 °C
Connectable conductor cross section solid-core

1 ... 35 mm²
