Auxiliary contacts, Easy TeSys Control, for LC1E contactors, 1NO + 1NC LAEN11

local index:

ATC087SCHN

Catalog number:

LAEN11

EAN code:

3606480325250

Auxiliary contacts, Easy TeSys Control, for LC1E contactors, 1NO + 1NC

Click on the photo to enlarge

Manufacturer: SCHNEIDER ELECTRIC

gG fuse [A]: 10

Number of contacts: 1 NO + 1 NC

Color: Gray

See full description

zł

gross / pcs. (including VAT 23%)

Dostępne 2 pcs.

Check

Odbierz w godzinę!

Details

Choose your wholesaler

Choose

Quantity pcs. (multiplicity: 1 )

Add to inquiry

Add to clipboard

Ask about the product

Product description Technical data Manufacturer details Bulk packaging Files to download

Product description

Additional 1NO+1NC auxiliary contact designed for use with Easy TeSys LC1E contactors. Equipped with instantaneous contacts with a load capacity of up to 10A at 690V AC. Connection is via screw terminals. Front mounting is quick and tool-free thanks to the snap-in mechanism. The product meets IEC, CCC, and EAC standards and is compliant with the Green Premium (RoHS/REACH) program.

Technical data

gG fuse [A]

10
Color

Gray
Minimum operating voltage UBmin [V]

17
Insulation resistance [MΩ]

>10
Mounting method

Front mounting
Mechanical durability

10,000,000 cycles
Rated thermal current [A]

8
Minimum operating temperature [°C]

-5

Number of contacts

1 NO + 1 NC
Maximum operating temperature [°C]

55
Rated insulation voltage [V]

690
Family

Easy TeSys
Level of security

IP20
Rated switching voltage [V]

690
Rated inrush current [A]

140
Minimum switching current [mA]

5

Other technical data

Number of contacts as change-over contact

0
Number of contacts as normally closed contact

1
Rated operation current Ie at AC-15, 230 V

8 A
Model

Integrable
Lamp holder

None

Number of contacts as normally open contact

1
Number of fault-signal switches

0
Type of electric connection

Screw connection
Mounting method

Front fastening

Manufacturer details

Manufacturer

Schneider Electric Polska
Address

02-673 Warszawa Konstruktorska 12 Polska
E-mail

poland.helpdesk@se.com

Bulk packaging

A kind of package	Sztuka	Karton	Paleta
Quantity	1 pcs.	100 pcs.	1600 pcs.
Weight (kg)	0,034	3,765	54,400
Volume (m3)	0,000	0,018	0,360
Width (m)	0,042	0,300	0,600
Length (m)	0,050	0,400	0,800
Depth (m)	0,028	0,150	0,750
