Acti9 P25M-4 motor circuit breaker 21107

local index:
ASN058SCHN
Catalog No:
21107
EAN code:
3303430211075
Manufacturer: SCHNEIDER ELECTRIC
Height [mm]: 89
Price:
135,24 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Acti9 P25M-4 motor circuit breaker

Technical data

  • Height [mm]
    89
  • PKWIU
    27.12.22.0

Other technical data

  • Release characteristic
    K
  • Number of protected poles
    3
  • Rated voltage
    400 V
  • Rated impulse withstand voltage Uimp
    6 kV
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
    100 kA
  • Frequency
    50 ... 60 Hz
  • Over voltage category
    3
  • Additional equipment possible
    Yes
  • Built-in depth
    44 mm
  • Ambient temperature during operating
    -20 ... 60 °C
  • Connectable conductor cross section solid-core
    1 ... 6 mm²
  • Number of poles (total)
    3
  • Rated current
    4 A
  • Rated insulation voltage Ui
    690 V
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
    100 kA
  • Voltage type
    AC
  • Concurrently switching neutral conductor
    No
  • Pollution degree
    3
  • Width in number of modular spacings
    2.5
  • Degree of protection (IP)
    IP20
  • Connectable conductor cross section multi-wired
    1 ... 6 mm²
