el12
Electrical apparatus
contactors
AC contactors
AC3-16A contactor, 230V AC LC1K1601P7
local index:
ATA045SCHN
Catalog No:
LC1K1601P7
EAN code:
3389110509113
Click on the photo to enlarge
Manufacturer:
SCHNEIDER ELECTRIC
Number of poles:
3
Control circuit voltage [V]:
230
Contact:
1NZ
See full description
Price:
42,29 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to cart
Add to clipboard
Print
Ask about the product
Product description
Technical data
Files to download
Product description
AC3-16A contactor, 230V AC
Technical data
Number of poles
3
Contact
1NZ
PKWIU
27.12.24.0
Control circuit voltage [V]
230
Rated operational current [A]
16
Other technical data
Rated control supply voltage AC 50 Hz
230 ... 230 V
Voltage type for actuating
AC
Rated operation current Ie at AC-3, 400 V
16 A
Rated operation current Ie at AC-4, 400 V
6 A
Modular version
No
Number of auxiliary contacts as normally closed contact
1
Number of normally closed contacts as main contact
0
Rated control supply voltage AC 60 Hz
230 ... 230 V
Rated operation current Ie at AC-1, 400 V
20 A
Rated operation power at AC-3, 400 V
7.5 kW
Rated operation power at AC-4, 400 V
2.2 kW
Number of auxiliary contacts as normally open contact
0
Type of electrical connection of main circuit
Screw connection
Number of normally open contacts as main contact
3
Files to download
PEP ecopassport SCHN-2015-025-EN_1.pdf
EoLI_ENVEOLI1503003_1.pdf
UK_Doc_LC_K_LP_K06-16_SC16040406A-UK.docx.pdf
