25A modular contactor ST25-04
local index:
ATM006FIFQ
Catalog number:
ST25-04
EAN code:
5908312593973
110
33
zł
gross / pcs.
(including VAT 23%)
Availability
Dostępne 394 pcs.
Check
Odbiór!
Odbierz w godzinę!
Details
Dostępność w oddziale
Choose your wholesaler
Choose
Quantity pcs.
(multiplicity:
1
)
Product description
The flood relay is used to detect the presence of electrically conductive liquids at the height of the mounted sensor.
Technical data
-
Number of contacts0NO 4NC
-
Level of securityIP20
-
Power [V]230
-
Package height [mm]150
-
Package weight [kg]0.3
-
PKWIU27.12.24.0
-
load current [A]25
-
Dimensions2 modules (35mm)
-
Rated operational current [A]25
-
Package width [mm]40
-
Maximum switching capacity for bulbs [W]9000
Other technical data
-
Rated operating voltage230 ... 230 V
-
Rated excitation voltage230 ... 230 V
-
Voltage type (excitation voltage)AC
-
Number of contacts as normally closed contact4
-
Slider for hand switchNo
-
Built-in depth65 mm
-
With day/night functionNo
-
Degree of protection (IP)IP20
-
Rated operation current25 A
-
Voltage type (operating voltage)AC
-
Number of contacts as normally open contact0
-
Max. incandescent lamp load9000 W
-
Width in number of modular spacings2
-
Additional equipment possibleNo
-
Hum-freeNo
Manufacturer details
-
ManufacturerF&F Filipowski S.K.
-
Address95-200 Pabianice Konstantynowska 79/81 Polska
-
E-mail
Bulk packaging
| A kind of package | Sztuka |
| Quantity | 1 pcs. |
| Weight (kg) | 0,214 |
| Width (m) | 0,040 |
| Length (m) | 0,085 |
| Depth (m) | 0,070 |
