ÖLFLEX TRUCK 170 FLRYY 1X2.5+8X1.5; Cable 7027069

Name: ÖLFLEX TRUCK 170 FLRYY 1X2.5+8X1.5; Cable
Brand: LAPP KABEL
SKU: KLC785LAPP
Price: 89.89 PLN
Availability: BackOrder

Indice locale:

KLC785LAPP

Numero di catalogo:

7027069

Codice EAN:

4044773281057

Clicca sulla foto per ingrandire

Produttore: LAPP KABEL

Prezzo:

89,89 zł

gross / metro

(inclusa IVA 23%)

Esaurito

Su ordinazione

Aggiungi alla richiesta di preventivo

Stampa

Chiedi informazioni sul prodotto

Dati tecnici Dettagli del produttore File da scaricare

Dati tecnici

Conductor material

Copper
Number of cores

9
Screen over stranding

None
Specification core insulation

Other
Core identification

Colour
Material outer sheath

Polyvinyl chloride (PVC)
Colour outer sheath

Black
Flame retardant according to IEC 60332-1-2

No
Flame retardant according to IEC 60332-3-22 (Cat A)

No
Flame retardant according to IEC 60332-3-24 (Cat C)

No
Low smoke according to EN IEC 61034-2

No
Halogen free according to EN IEC 60754-2

No
Reaction-to-fire according to EN 13501-6: Smoke production

None
Reaction-to-fire according to EN 13501-6: Acidity

None
Outer diameter approx.

11.7 mm
Permitted cable outer temperature after assembling without vibration

-40 ... 85 °C
Weight

233 kg/km

Conductor surface

Bare
Screen over stranding element

None
Material core insulation

Polyvinyl chloride (PVC)
Core identification according to HD 308 S2

No
With protective conductor

No
Specification material outer sheath

Other
Cable geometry

Round
Flame retardant according to IEC 60332-3-21 (Cat A F/R)

No
Flame retardant according to IEC 60332-3-23 (Cat B)

No
Flame retardant according to IEC 60332-3-25 (Cat D)

No
Halogen free according to EN IEC 60754-1

No
Reaction-to-fire according to EN 13501-6: Class

None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles

None
Oil resistant according to EN IEC 60811-404

No
Min. permitted bending radius, stationary application/permanent installation

140.4 mm
Nominal voltage U

60 V
