Ölflex Lift F 16G1 300/500V cable 0042021
Místní index:
KUU234LAPP
Katalogové číslo.:
0042021
EAN kód:
4044773050349
objemné produkt
Cena:
27,34 zł
gross / bm.
(včetně DPH 23%)
Na zakázku
Přidat do žádosti o cenovou nabídku
Vytisknout
Dotaz na výrobek
Popis produktu
Ölflex Lift F 16G1 300/500V cable
Technické údaje
-
Number of veins16
-
Vein materialCopper
-
Core cross-section [mm²]1
-
Accurate colorBlack
-
ColorBlack
-
Rated voltage [V]300/500
-
CoreCord
-
Insulation materialPVC
Další technické údaje
-
Conductor materialCopper
-
Nominal cross section conductor1 mm²
-
Number of cores16
-
Screen over strandingNone
-
Specification core insulationOther
-
Core identificationNumbers
-
Material outer sheathPolyvinyl chloride (PVC)
-
Colour outer sheathBlack
-
Flame retardant according to IEC 60332-1-2Yes
-
Flame retardant according to IEC 60332-3-22 (Cat A)No
-
Flame retardant according to IEC 60332-3-24 (Cat C)No
-
Low smoke according to EN IEC 61034-2No
-
Halogen free according to EN IEC 60754-2No
-
Reaction-to-fire according to EN 13501-6: Smoke productionNone
-
Reaction-to-fire according to EN 13501-6: AcidityNone
-
Cable width approx.48.5 mm
-
Permitted cable outer temperature during assembling/handling-15 ... 70 °C
-
Nominal voltage U500 V
-
Conductor surfaceBare
-
Conductor categoryClass 6 = very flexible
-
Screen over stranding elementNone
-
Material core insulationPolyvinyl chloride (PVC)
-
Core identification according to HD 308 S2No
-
With protective conductorYes
-
Specification material outer sheathOther
-
Cable geometryFlat
-
Flame retardant according to IEC 60332-3-21 (Cat A F/R)No
-
Flame retardant according to IEC 60332-3-23 (Cat B)No
-
Flame retardant according to IEC 60332-3-25 (Cat D)No
-
Halogen free according to EN IEC 60754-1No
-
Reaction-to-fire according to EN 13501-6: ClassNone
-
Reaction-to-fire according to EN 13501-6: Flaming droplets/particlesNone
-
Oil resistant according to EN IEC 60811-404No
-
Cable height approx.4.7 mm
-
Nominal voltage U0300 V
-
Weight521 kg/km
Podrobnosti o výrobci
-
VýrobceLapp Kabel Sp. z o.o.
-
Adresa55-040 Kobierzyce ul. Profesjonalna 1 Biskupice Podgórne 1
-
DIČ8971621588
