ÖLFLEX HEAT 125 C MC 2X0.5; Cable 1024400
Indice locale:
KLC056LAPP
Numero di catalogo:
1024400
Codice EAN:
4044777069279
Produttore:
LAPP KABEL
Prezzo:
54,87 zł
gross / metro
(inclusa IVA 23%)
Su ordinazione
Aggiungi alla richiesta di preventivo
Stampa
Chiedi informazioni sul prodotto
Dati tecnici
Altri dati tecnici
-
Conductor materialCopper
-
Nominal cross section conductor0.5 mm²
-
Number of cores2
-
Stranding elementOther
-
Material core insulationOther
-
Core identification according to HD 308 S2Yes
-
With protective conductorNo
-
Specification material outer sheathOther
-
ScreenYes
-
Flame retardant according to IEC 60332-1-2No
-
Flame retardant according to IEC 60332-3-22 (Cat A)Yes
-
Flame retardant according to IEC 60332-3-24 (Cat C)Yes
-
Low smoke according to EN IEC 61034-2No
-
Halogen free according to EN IEC 60754-2No
-
Reaction-to-fire according to EN 13501-6: Smoke productions1a
-
Reaction-to-fire according to EN 13501-6: Aciditya1
-
Outer diameter approx.6.8 mm
-
Min. permitted bending radius, stationary application/permanent installation27.2 mm
-
Permitted cable outer temperature after assembling without vibration-55 ... 125 °C
-
Nominal voltage U500 V
-
Conductor surfaceTinned
-
Conductor categoryClass 5 = flexible
-
Screen over stranding elementNone
-
Screen over strandingBraiding
-
Specification core insulationOther
-
Core identificationColour
-
Material outer sheathOther
-
Colour outer sheathBlack
-
Cable geometryRound
-
Flame retardant according to IEC 60332-3-21 (Cat A F/R)No
-
Flame retardant according to IEC 60332-3-23 (Cat B)Yes
-
Flame retardant according to IEC 60332-3-25 (Cat D)Yes
-
Halogen free according to EN IEC 60754-1Yes
-
Reaction-to-fire according to EN 13501-6: ClassB2ca
-
Reaction-to-fire according to EN 13501-6: Flaming droplets/particlesNone
-
Oil resistant according to EN IEC 60811-404No
-
Min. permitted bending radius, moving application/free movement102 mm
-
Permitted cable outer temperature during assembling/handling-35 ... 120 °C
-
Nominal voltage U0300 V
-
Weight45 kg/km
