ÖLFLEX CLASSIC 100 BK 0.6/1 kV 2x1.5; Cable 1120462
Místní index:
KSA4L5LAPP
Katalogové číslo.:
1120462
EAN kód:
4044773769944
Výrobce:
LAPP KABEL
objemné produkt
Cena:
26,58 zł
gross / bm.
(včetně DPH 23%)
Na zakázku
Přidat do žádosti o cenovou nabídku
Vytisknout
Dotaz na výrobek
Technické údaje
Další technické údaje
-
Conductor materialCopper
-
Nominal cross section conductor1.5 mm²
-
Number of cores2
-
Screen over stranding elementNone
-
Material core insulationPolyvinyl chloride (PVC)
-
Core identification according to HD 308 S2Yes
-
ScreenNo
-
Material outer sheathPolyvinyl chloride (PVC)
-
Colour outer sheathBlack
-
Flame retardant according to IEC 60332-1-2Yes
-
Flame retardant according to IEC 60332-3-22 (Cat A)No
-
Flame retardant according to IEC 60332-3-24 (Cat C)No
-
Low smoke according to EN IEC 61034-2No
-
Halogen free according to EN IEC 60754-2No
-
Reaction-to-fire according to EN 13501-6: AcidityNone
-
Outer diameter approx.9.6 mm
-
Min. permitted bending radius, stationary application/permanent installation38.4 mm
-
Permitted cable outer temperature after assembling without vibration-40 ... 80 °C
-
Nominal voltage U1 kV
-
Conductor surfaceBare
-
Conductor categoryClass 5 = flexible
-
Stranding elementOther
-
Screen over strandingNone
-
Specification core insulationOther
-
Core identificationColour
-
With protective conductorNo
-
Specification material outer sheathOther
-
Cable geometryRound
-
Flame retardant according to IEC 60332-3-21 (Cat A F/R)No
-
Flame retardant according to IEC 60332-3-23 (Cat B)No
-
Flame retardant according to IEC 60332-3-25 (Cat D)No
-
Halogen free according to EN IEC 60754-1No
-
Reaction-to-fire according to EN 13501-6: ClassEca
-
Oil resistant according to EN IEC 60811-404No
-
Min. permitted bending radius, moving application/free movement144 mm
-
Permitted cable outer temperature during assembling/handling-30 ... 70 °C
-
Nominal voltage U00.6 kV
-
Weight123 kg/km
Dane CPR (Construction Products Regulation)
-
Numer notyfikowanego laboratorium badawczego CE:0366
-
Wydzielane substancje niebezpieczne:NPD
-
Numer referencyjny DoP (DWU)UILCPRDoP17_1120450-1_A
-
Oznaczenie produktuÖLFLEX CLASSIC 100 BK 0,6/1 KV 2X1,5
-
Reakcja na ogień:Eca
-
Zharmonizowana specyfikacja techniczna (norma):EN 50575:2014 + A1:2016
Podrobnosti o výrobci
-
VýrobceLapp Kabel Sp. z o.o.
-
Adresa55-040 Kobierzyce ul. Profesjonalna 1 Biskupice Podgórne 1
-
DIČ8971621588
