Olflex cable FD 90 1X150 0026626
Indeks lokalny:
KSA458LAPP
Numer katalogowy:
0026626
Kod EAN:
4044773034554
Produkt wielkogabarytowy
Cena:
112,99 zł
gross / mb.
(w tym VAT 23%)
Odbiór za 1h
Ilość mb.
(wielokrotność:
1
)
Dodaj do zapytania ofertowego
Dodaj do schowka
Drukuj
Zapytaj o produkt
Opis produktu
Olflex cable FD 90 1X150
Dane techniczne
-
ShieldedNO
-
ColorBlack
-
Rated voltage [V]600/1000
-
CoreCord
-
Operating temperature range (fixed installation) [°C]from -40 to +80
-
Insulation materialPVC
-
Number of veins1
-
Vein materialCopper
-
Core cross-section [mm²]150
-
Operating temperature range (mobile installation) [°C]from -5 to +70
-
Protective wireNO
Pozostałe dane techniczne
-
Conductor materialCopper
-
Nominal cross section conductor150 mm²
-
Conductor categoryClass 6 = very flexible
-
Screen over stranding elementNone
-
Material core insulationPolyvinyl chloride (PVC)
-
Core identification according to HD 308 S2No
-
With protective conductorNo
-
Specification material outer sheathOther
-
Cable geometryRound
-
Flame retardant according to IEC 60332-3-21 (Cat A F/R)No
-
Flame retardant according to IEC 60332-3-23 (Cat B)No
-
Flame retardant according to IEC 60332-3-25 (Cat D)No
-
Halogen free according to EN IEC 60754-1No
-
Reaction-to-fire according to EN 13501-6: ClassNone
-
Oil resistant according to EN IEC 60811-404No
-
Min. permitted bending radius, moving application with forced guidance188.3 mm
-
Min. permitted bending radius, stationary application/permanent installation75.3 mm
-
Permitted cable outer temperature after assembling without vibration-40 ... 80 °C
-
Nominal voltage U1 kV
-
Conductor surfaceBare
-
Nominal cross section conductor (AWG)250 kcmil
-
Number of cores1
-
Screen over strandingNone
-
Specification core insulationOther
-
ScreenNo
-
Material outer sheathPolyvinyl chloride (PVC)
-
Colour outer sheathBlack
-
Flame retardant according to IEC 60332-1-2Yes
-
Flame retardant according to IEC 60332-3-22 (Cat A)No
-
Flame retardant according to IEC 60332-3-24 (Cat C)No
-
Low smoke according to EN IEC 61034-2No
-
Halogen free according to EN IEC 60754-2No
-
Reaction-to-fire according to EN 13501-6: AcidityNone
-
Outer diameter approx.25.1 mm
-
Min. permitted bending radius, moving application/free movement188.3 mm
-
Permitted cable outer temperature during assembling/handling-5 ... 70 °C
-
Nominal voltage U00.6 kV
-
Weight1669 kg/km
Dane producenta
-
ProducentLapp Kabel Sp. z o.o.
-
Adres55-040 Kobierzyce ul. Profesjonalna 1 Biskupice Podgórne 1
-
NIP8971621588
