Installation cable H07V-K LGY 1X1.5 yellow-green 5907702813790

Technical data: the largest nominal diameter of the wire in the strand: 0.26 mm rated insulation thickness: 0.7 mm approximate outer diameter of the cable: 3.4 mm maximum conductor resistance at 20°C: 13.3 Ω/km minimum insulation resistance at 70°C: 0.01 mΩ x km rated voltage: 450/750V number and nominal cross-section of wires: 1 x 1.5 ÷ 150 mm2 conductor: stranded copper, flexible, class 5, according to PN-EN 60228:2007 insulation: ordinary insulating PVC puck: 100 m Application: permanently secured connections inside devices and inside or outside luminaires suitable for laying in installation pipes mounted on the surface or embedded in it for signaling or control circuits
