el12 Cables and wires Copper cables for permanent installation Installation wires

H07V-U 1x2.5 yellow RE Power cable, installation, single-core, with solid core and PVC insulation 172105067C0100

local index:
KPD009NKTQ
Catalog number:
172105067C0100
EAN code:
5907802045169
H07V-U 1x2.5 yellow RE Power cable, installation, single-core, with solid core and PVC insulation
H07V-U 1x2.5 yellow RE Power cable, installation, single-core, with solid core and PVC insulation

Click on the photo to enlarge

Manufacturer: NKT
Price:
2,73 zł
gross / m.
(including VAT 23%)
Out of stock
On request
Add to inquiry
Print
Technical data Manufacturer details Files to download

Technical data

Other technical data

  • Conductor material
    Copper
  • Nominal cross section conductor
    2.5 mm²
  • Conductor resistance at 20 °C
    7.41 Ω/km
  • Specification core insulation
    Other
  • Identification/coding colour core
    Other
  • Core colour
    Several
  • Max. conductor temperature
    70 °C
  • Drain wire
    No
  • Armouring/reinforcement
    None
  • Cable geometry
    Round
  • Reaction-to-fire according to EN 13501-6: Smoke production
    None
  • Reaction-to-fire according to EN 13501-6: Acidity
    None
  • Flame retardant
    According to IEC/EN 60332-1-2
  • Low temperature resistant according to EN 60811-504+505+506
    No
  • Wytrzymałość (trwałość) izolacji
    None
  • Min. permitted bending radius, stationary application/permanent installation
    5 mm
  • Nominal voltage U0
    450 V
  • Circuit integrity
    None
  • Suitable as installation cable
    Yes
  • Suitable as medium-voltage cable
    No
  • Certified as airport lighting cable
    No
  • Circuit integrity according to EN 50200
    No
  • Circuit integrity according to IEC 60331-3
    No
  • Flame retardant according to EN 60332-1-2
    Yes
  • Flame retardant according to EN 60332-3-22 (Cat A)
    No
  • Flame retardant according to EN 60332-3-24 (Cat C)
    No
  • Halogen free according to EN 60754-1
    No
  • Halogen free according to EN 60754-3
    No
  • Conductor surface
    Bare
  • Conductor category
    Class 1 = solid
  • Material core insulation
    Polyvinyl chloride (PVC)
  • Core identification according to HD 308 S2
    Yes
  • Core identification
    Colour
  • With protective conductor
    No
  • Screen
    No
  • Protective barrier
    None
  • Material outer sheath
    None
  • Reaction-to-fire according to EN 13501-6: Class
    Eca
  • Reaction-to-fire according to EN 13501-6: Flaming droplets/particles
    None
  • Halogen free according to EN 60754-1/2
    No
  • Low smoke (according to EN 61034-2)
    No
  • Oil resistant according to EN IEC 60811-404
    No
  • Outer diameter approx.
    3.27 mm
  • Permitted cable outer temperature after assembling without vibration
    -40 ... +70 °C
  • Nominal voltage U
    750 V
  • Shape of conductor
    Round
  • Certified for shipboard application
    No
  • Suitable as high-voltage cable
    No
  • Weight
    30 kg/km
  • Circuit integrity according to EN 50200 annex E
    No
  • Circuit integrity according to IEC 60331-21
    No
  • Flame retardant according to EN 60332-3-21 (Cat A F/R)
    No
  • Flame retardant according to EN 60332-3-23 (Cat B)
    No
  • Flame retardant according to EN 60332-3-25 (Cat D)
    No
  • Halogen free according to EN 60754-2
    No

Dane CPR (Construction Products Regulation)

  • Wydzielane substancje niebezpieczne:
    NPD
  • Numer referencyjny DoP (DWU)
    DOP000035
  • Oznaczenie produktu
    H07V-U 1x2,5 żółty RE
  • Reakcja na ogień:
    Eca
  • Zharmonizowana specyfikacja techniczna (norma):
    EN 50575:2014, EN50575:2014/A1:2016
  • Zastosowanie:
    Dostawa energii (oraz zastosowania komunikacyjne) w budynkach i innych obiektach budowlanych w celu ograniczenia powstawania i rozprzestrzeniania się ognia i dymu

Manufacturer details

  • Manufacturer
    NKT S.A.
  • Address
    43-502 Warszowice Gajowa 3 Polska
  • E-mail
    info.pl@nkt.com
