H07RN-F, ENHANCED VERSION 4X1.5; Cable 4533064
Indice locale:
KGO039LAPP
Numero di catalogo:
4533064
Codice EAN:
4044776707523
Produttore:
LAPP KABEL
Prezzo:
52,20 zł
gross / metro
(inclusa IVA 23%)
Su ordinazione
Quantità metro
(multiplo:
1
)
Aggiungi alla richiesta di preventivo
Aggiungi agli appunti
Stampa
Chiedi informazioni sul prodotto
Dati tecnici
Altri dati tecnici
-
Conductor materialCopper
-
Nominal cross section conductor1.5 mm²
-
Number of cores4
-
Screen over strandingNone
-
Specification core insulationOther
-
Core identificationColour
-
Material outer sheathRubber
-
Colour outer sheathBlack
-
Cable geometryRound
-
Flame retardant according to IEC 60332-3-21 (Cat A F/R)No
-
Flame retardant according to IEC 60332-3-23 (Cat B)No
-
Flame retardant according to IEC 60332-3-25 (Cat D)No
-
Halogen free according to EN IEC 60754-1Yes
-
Reaction-to-fire according to EN 13501-6: ClassEca
-
Reaction-to-fire according to EN 13501-6: Flaming droplets/particlesNone
-
Oil resistant according to EN IEC 60811-404No
-
Min. permitted bending radius, stationary application/permanent installation52.4 mm
-
Permitted cable outer temperature after assembling without vibration-50 ... 90 °C
-
Nominal voltage U750 V
-
Conductor surfaceBare
-
Conductor categoryClass 5 = flexible
-
Screen over stranding elementNone
-
Material core insulationRubber
-
Core identification according to HD 308 S2Yes
-
With protective conductorNo
-
Specification material outer sheathOther
-
ScreenNo
-
Flame retardant according to IEC 60332-1-2Yes
-
Flame retardant according to IEC 60332-3-22 (Cat A)No
-
Flame retardant according to IEC 60332-3-24 (Cat C)No
-
Low smoke according to EN IEC 61034-2Yes
-
Halogen free according to EN IEC 60754-2No
-
Reaction-to-fire according to EN 13501-6: Smoke productionNone
-
Reaction-to-fire according to EN 13501-6: AcidityNone
-
Min. permitted bending radius, moving application/free movement78.6 mm
-
Permitted cable outer temperature during assembling/handling-40 ... 80 °C
-
Nominal voltage U0450 V
-
Weight200 kg/km
