H07RN-F, ENHANCED VERSION 1X70; Cable 4533009
Lokaler Index:
KGO032LAPP
Katalognummer:
4533009
EAN-Code:
4044776706977
Hersteller:
LAPP KABEL
Großformatiges Produkt
Preis:
363,50 zł
gross / lfm.
(inklusive MwSt 23%)
Auf Bestellung
Zur Angebotsanfrage hinzufügen
Drucken
Fragen Sie nach dem Produkt
Technische Daten
Weitere technische Daten
-
Conductor materialCopper
-
Nominal cross section conductor70 mm²
-
Number of cores1
-
Screen over strandingNone
-
Specification core insulationOther
-
With protective conductorNo
-
Specification material outer sheathOther
-
ScreenNo
-
Flame retardant according to IEC 60332-1-2Yes
-
Flame retardant according to IEC 60332-3-22 (Cat A)No
-
Flame retardant according to IEC 60332-3-24 (Cat C)No
-
Low smoke according to EN IEC 61034-2Yes
-
Halogen free according to EN IEC 60754-2No
-
Reaction-to-fire according to EN 13501-6: Smoke productionNone
-
Reaction-to-fire according to EN 13501-6: AcidityNone
-
Min. permitted bending radius, moving application/free movement139.8 mm
-
Permitted cable outer temperature during assembling/handling-40 ... 80 °C
-
Nominal voltage U0450 V
-
Weight914 kg/km
-
Conductor surfaceBare
-
Conductor categoryClass 5 = flexible
-
Screen over stranding elementNone
-
Material core insulationRubber
-
Core identification according to HD 308 S2No
-
Material outer sheathRubber
-
Colour outer sheathBlack
-
Cable geometryRound
-
Flame retardant according to IEC 60332-3-21 (Cat A F/R)No
-
Flame retardant according to IEC 60332-3-23 (Cat B)No
-
Flame retardant according to IEC 60332-3-25 (Cat D)No
-
Halogen free according to EN IEC 60754-1Yes
-
Reaction-to-fire according to EN 13501-6: ClassEca
-
Reaction-to-fire according to EN 13501-6: Flaming droplets/particlesNone
-
Oil resistant according to EN IEC 60811-404No
-
Min. permitted bending radius, stationary application/permanent installation93.2 mm
-
Permitted cable outer temperature after assembling without vibration-50 ... 90 °C
-
Nominal voltage U750 V
Hersteller-Details
-
HerstellerLapp Kabel Sp. z o.o.
-
Adresse55-040 Kobierzyce ul. Profesjonalna 1 Biskupice Podgórne 1
-
Steueridentifikationsnummer8971621588
