H05VV-F 5G1.5 white Flexible multi-core power cable with PVC insulation and sheath, round 160063023C0100

Name: H05VV-F 5G1.5 white Flexible multi-core power cable with PVC insulation and sheath, round
Brand: NKT
SKU: KGM040NKTQ
Price: 10.15 PLN
Availability: BackOrder

local index:

KGM040NKTQ

Catalog number:

160063023C0100

EAN code:

5907802043660

H05VV-F 5G1.5 white Flexible multi-core power cable with PVC insulation and sheath, round

Click on the photo to enlarge

Manufacturer: NKT

Price:

10,15 zł

gross / m.

(including VAT 23%)

Out of stock

On request

Add to inquiry

Print

Ask about the product

Technical data Manufacturer details Files to download

Technical data

Other technical data

Conductor material

Copper
Nominal cross section conductor

1.5 mm²
Conductor category

Class 5 = flexible
Number of cores

5
Material core insulation

Polyvinyl chloride (PVC)
Core identification according to HD 308 S2

Yes
Core identification

Colour
Max. conductor temperature

70 °C
Drain wire

No
Armouring/reinforcement

None
Specification material outer sheath

Other
Cable geometry

Round
Reaction-to-fire according to EN 13501-6: Smoke production

None
Reaction-to-fire according to EN 13501-6: Acidity

None
Flame retardant

According to IEC/EN 60332-1-2
Low temperature resistant according to EN 60811-504+505+506

No
Outer diameter approx.

9.84 mm
Permitted cable outer temperature after assembling without vibration

-30 ... 70 °C
Shape of conductor

Round
Certified for shipboard application

No
Suitable as high-voltage cable

No
Weight

163

Conductor surface

Bare
Diameter conductor

1.4 mm
Conductor resistance at 20 °C

13.3
Twisted cores

No
Specification core insulation

Other
Identification/coding colour core

Other
Core colour

Several
Screen

No
Protective barrier

None
Material outer sheath

Polyvinyl chloride (PVC)
Colour outer sheath

White
Reaction-to-fire according to EN 13501-6: Class

Eca
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles

None
Halogen free according to EN 60754-1/2

No
Low smoke (according to EN 61034-2)

No
Oil resistant according to EN IEC 60811-404

No
Permitted cable outer temperature during assembling/handling

5 ... 40 °C
Circuit integrity

None
Suitable as installation cable

Yes
Suitable as medium-voltage cable

No
Certified as airport lighting cable

No

Dane CPR (Construction Products Regulation)

Wydzielane substancje niebezpieczne:

NPD
Numer referencyjny DoP (DWU)

DOP000404
Oznaczenie produktu

H05VV-F 5G1,5 white

Reakcja na ogień:

Eca
Zharmonizowana specyfikacja techniczna (norma):

EN 50575:2014, EN50575:2014/A1:2016
Zastosowanie:

Dostawa energii (oraz zastosowania komunikacyjne) w budynkach i innych obiektach budowlanych w celu ograniczenia powstawania i rozprzestrzeniania się ognia i dymu
