el12 Cables and wires Copper wires for mobile receivers Workshop shear cables in polyvinyl insulation and sheath

H05RR-F 3G0.75 mm2 cable 5901854403205

local index:
KGN021ELPA
Catalog No:
5901854403205
EAN code:
5901854403205
H05RR-F 3G0.75 mm2 cable
H05RR-F 3G0.75 mm2 cable

Click on the photo to enlarge

Manufacturer: ELPAR
Number of veins: 3
Color: Gray
Vein material: Copper
See full description
Large-size product
Price:
0,79 €
gross / m.
(including VAT 23%)
Delivery in 3h
Product on individual request
Pickup in 1h
Quantity m.
(multiplicity:
1
)
Print
Product description Technical data Manufacturer details

Product description

H05RR-F 3G0.75 mm2 cable

Technical data

  • Number of veins
    3
  • Vein material
    Copper
  • Core cross-section [mm²]
    0.75
  • Accurate color
    Gray
  • Color
    Gray
  • Rated voltage [V]
    300/500
  • Core
    Cord
  • Insulation material
    Gum

Other technical data

  • Nominal cross section conductor
    0.75 mm²
  • Number of cores
    3
  • Material core insulation
    Rubber
  • Core identification
    Colour
  • Screen over stranding
    None
  • Material outer sheath
    Rubber
  • Colour outer sheath
    Black
  • Reaction-to-fire according to EN 13501-6: Class
    Eca
  • Reaction-to-fire according to EN 13501-6: Flaming droplets/particles
    None
  • Halogen free according to EN 60754-1/2
    No
  • Oil resistant according to EN IEC 60811-404
    No
  • Min. permitted bending radius, stationary application/permanent installation
    20.1 mm
  • Nominal voltage U
    500 V
  • Conductor category
    Class 5 = flexible
  • Stranding element
    No
  • Specification core insulation
    Rubber - ethylene propylene rubber (EPR)
  • Screen over stranding element
    None
  • Suspension element
    None
  • Specification material outer sheath
    Rubber - ethylene propylene rubber (EPR)
  • Torsion resistant
    No
  • Reaction-to-fire according to EN 13501-6: Smoke production
    None
  • Reaction-to-fire according to EN 13501-6: Acidity
    None
  • Low temperature resistant according to EN 60811-504+505+506
    No
  • Outer diameter approx.
    6.7 mm
  • Nominal voltage U0
    300 V

Manufacturer details

  • Manufacturer
    Fabryka Kabli ELPAR sp. z o.o.
  • Address
    21-200 Parczew Laskowska 1 Polska
  • E-mail
    info@elpar.pl
