Flexible power cables with insulation and rubber sheath H07RN-F 4x4 IP0244

Indice locale:
KGO118BITN
Numero di catalogo:
IP0244
Codice EAN:
5902956084224
Produttore: BITNER
Color: Transparent
Maximum conductor temperature during short-circuit [°C]: 200
Maximum working conductor temperature [°C]: 60
Prodotto di grandi dimensioni
Prezzo:
4,96 €
gross / metro
(inclusa IVA 23%)
Consegna in 3 ore
Prodotto su richiesta individuale
Raccolta in 1h
Quantità metro
(multiplo:
1
)
Aggiungi alla richiesta di preventivo
Stampa

Descrizione del prodotto

Power cable with copper, multi-wire flexible conductors, EPR rubber insulation, oil-resistant and flame-retardant chloroprene rubber sheath. H07 RN-F cables are designed to power mobile and portable receivers working in industry, agriculture, opencast mines, in power control, protection and control devices, as well as to supply electrical energy to electrical receivers/machines in a very wide environmental range. The cables can be used indoors and outdoors without restrictions, also directly in the ground and in water.

Dati tecnici

  • Color
    Transparent
  • Maximum working conductor temperature [°C]
    60
  • Voltage test [V]
    2000
  • Accurate color
    Transparent
  • Maximum conductor temperature during short-circuit [°C]
    200
  • Capacity [nF/km]
    core/core = 70 to 250, core/screen = 110 to 410
  • Diameter [mm]
    17.9
  • PKWIU
    27.32.13

Dane CPR (Construction Products Regulation)

  • Wydzielane substancje niebezpieczne:
    brak
  • Numer referencyjny DoP (DWU)
    0087/DWU/S/2017
  • Oznaczenie produktu
    H07RN-F 4x4
  • Reakcja na ogień:
    Fca
  • Zharmonizowana specyfikacja techniczna (norma):
    PN-EN 50575
  • Zastosowanie:
    Dostarczanie energii do budynków i innych obiektów budowlanych z uwzględnieniem ograniczenia powstawania i rozprzestrzeniania się ognia.

Dettagli del produttore

  • Produttore
    BITNER Zakłady Kablowe Sp. z o.o.
  • Indirizzo
    30-009 Kraków Friedleina 3/3 Polska
